Features
1.Available in mill galvanized and hot dipped galvanized.
2.Available in 8" and 12".
Product Information
ASTM A951/A951M - (Standard Specification for Steel)
Wire For Mason Joint Reinforcement
ASTM A82/A82M - (Cold Drawn Steel Wire)
Tensile Strength - 80,000 psi
Yield Point - 70,000 psi
Coatings conform to the following specifications:
ASTM A641/A641M (0.1 oz/Ft2 ) for Mill Galvanized coating
ASTM A153/A153M-B2 (1.5 oz/Ft2 ) for Hot-Dip Galvanized
Additional Information
Wire Diameter
1.9 Gauge (3.75 mm) side rods and cross rods.
2.Cross Rods welded at 16” on center.
3.First Cross Rods welded 12” in from each end to allow lap spaces per code requirements.
Product Advantages
1. High strength and durability: Made of high-quality steel wire, it has excellent strength and durability, able to withstand pressure and weight, ensuring the stability of the structure.
2. Corrosion resistance: The surface treatment, either galvanizing or hot-dipped galvanizing, provides excellent corrosion resistance, enabling the product to be used in humid and corrosive environments and extending its service life.
3. Easy installation: The product is designed for easy installation and can save installation time and cost.
4. Attractive appearance: The product has a neat and attractive appearance, adding to the overall aesthetic of the building.
5. Versatile application: Suitable for use in various masonry buildings at T-junctions, such as walls, columns, and doors and windows, to provide additional strength and stability.
